CIRCUIT BREAKER, RCCB, 1P+N, 230-240V, 20A

CIRCUIT BREAKER WITH OVERCURRENT PROTECTION
TRIPPING CHARACTERISTIC: C
TYPE OF RESIDUAL CURRENT: A TYPE
RATED VOLTAGE (UR): 230 V
RATED OPERATIONAL VOLTAGE: 230-240 V AC
RATED INSULATION VOLTAGE (UI): 500 V
TEST VOLTAGE (UT): 170-264 V
DIELECTRIC TEST VOLTAGE: 2 KV
PRIMARY RATED IMPULSE WITHSTAND VOLTAGE: 4 KV
INPUT VOLTAGE TYPE: AC
RATED CURRENT (IN): 20 A
RATED RESIDUAL CURRENT: 30 MA
RATED SHORT-CIRCUIT CAPACITY (ICN): 10 KA
RATED ULTIMATE SHORT-CIRCUIT BREAKING CAPACITY (ICU): 15 KA
RATED CONDITIONAL SHORT-CIRCUIT CURRENT (INC): 15 KA
RATED SERVICE SHORT-CIRCUIT BREAKING CAPACITY (ICS): 11.2 KA
LEAKAGE CURRENT TYPE: A
FREQUENCY (F): 50/60 HZ
POWER LOSS: 3.6 W
POWER SUPPLY CONNECTION: ARBITRARY
CONTACT POSITION INDICATION: RED ON / GREEN OFF
ENERGY LIMITING CLASS: 3
ELECTRICAL ENDURANCE: 10000 CYCLE
MECHANICAL ENDURANCE (NENDU): 20000 CYCLE
NUMBER OF POLES: 2
NUMBER OF PROTECTED POLES: 1
NUMBER OF MODULAR SPACINGS PER DIN RAIL: 2
FAULT INDICATION: BLUE FLAG ON TOGGLE
OPERATING CHARACTERISTIC: INSTANTANEOUS
OVERVOLTAGE CATEGORY: III
POSITION OF NEUTRAL TERMINALS: RIGHT
TIGHTENING TORQUE: 2.8 N?M
CERTIFICATE ATTACHED ? AHJ PPROVED
