CIRCUIT BREAKER, RCBO, 2POLE, 230V

CIRCUIT BREAKER, TRIPPING CHARACTERISTIC: C TYPE OF RESIDUAL CURRENT:AC TYPE RATED VOLTAGE (UR):230 V RATED OPERATIONAL VOLTAGE:230 / 240 V AC RATED INSULATION VOLTAGE (UI):500 V TEST VOLTAGE (UT):110 … 264 V DIELECTRIC TEST VOLTAGE:2 KV PRIMARY RATED IMPULSE WITHSTAND VOLTAGE: 4 KV INPUT VOLTAGE TYPE:AC RATED CURRENT (IN):10 A RATED RESIDUAL CURRENT: 300 MA RATED SHORT-CIRCUIT CAPACITY: 6 KA RATED ULTIMATE SHORT-CIRCUIT BREAKING CAPACITY (ICU):10 KA RATED CONDITIONAL SHORT-CIRCUIT CURRENT (INC): 10 KA RATED SERVICE SHORT-CIRCUIT BREAKING CAPACITY (ICS):7.5 KA MAXIMUM SURGE CURRENT: 0 KA LEAKAGE CURRENT TYPE: AC FREQUENCY (F): 50/60 HZ RATED FREQUENCY (F):230 … 240 V AC POWER LOSS: 1.8 W POWER SUPPLY CONNECTION: ARBITRARY CONTACT POSITION INDICATION: RED ON / GREEN OFF ENERGY LIMITING CLASS: 3 ELECTRICAL ENDURANCE: 10000 CYCLE MECHANICAL ENDURANCE :20000 CYCLE NUMBER OF POLES:2 NUMBER OF PROTECTED POLES: 1 NUMBER OF MODULAR SPACINGS PER DIN RAIL: 2 FAULT INDICATION: BLUE FLAG ON TOGGLE OPERATING CHARACTERISTIC: INSTANTANEOUS MOUNTING TYPE: ON DIN RAIL EN 60715 (35MM) BY MEANS OF MOUNTING CLIP RELEASE TYPE:C SCREW TERMINAL TYPE: FAILSAFE BI-DIRECTIONAL CYLINDER-LIFT TERMINAL CERTIFICATION ATTACHED – AHJ APPROVED
