CABLE ASSEMBLY, PVC, RED, 24 AWG, 400 MHZ

SHEATH COLOR: REDSTANDARD: CATEGORY 6ACR (100 M/DB MIN.): 100 MHZ: 24.5; 250 MHZ: 5.5 ATTENUATION (100 M/DB MIN.): 100 MHZ: 19.8; 250 MHZ: 32.8; 300 MHZ: 36.4; 400 MHZ: 43.0 CHARACTERISTIC IMPEDANCE: 1~250 MHZ: 100 ±15 OHMS CONDUCTORS: BARE SOLID COPPER JACKET: FR PVC (FLAME RETARDANT POLYVINYL CHLORIDE) INSULATION: HDPE (HIGH-DENSITY POLYETHYLENE) DELAY SKEW: 1-400 MHZ, 536 NS/100 M MAXIMUM OUTER DIAMETER: 7.0 ± 0.2 MMELFEXT: (DB MIN.) 100 MHZ: 27.8; 250 MHZ: 19.8; 300 MHZ: 18.2; 400 MHZ: 15.7 GAUGE: 24 AWG MUTUAL CAPACITANCE (MAXIMUM): 56 PF/M NEXT (DB MIN.) : 100 MHZ: 44.3; 250 MHZ: 38.3; 300 MHZ: 37.2; 400 MHZ: 35.3 PS-ACR: 100 MHZ: 22.5; 250 MHZ: 3.5 PS-ELFEXT: 100 MHZ: 24.8; 250 MHZ: 16.8; 300 MHZ: 15.2; 400 MHZ: 12.7 PS-NEXT: 100 MHZ: 42.3; 250 MHZ: 36.3; 300 MHZ: 35.2; 400 MHZ: 33.3 RETURN LOSS: 400 MHZ SHIELD: ALUMINUM/MYLAR TAPE WITH DRAIN WIREUNIT OF MEASURE: ROLL (CONTAINS 1000 FEET)NON-ELECTRICAL CLARIFICATION ATTACHED
